Aluminum Wires Rods

Alüminyum Filmaşin

Material :
Continuous Casting 6101 T4 Almetec Grade Aluminium Wire Rod.
Technical Specifications :
Guaranteed chermical composition : EN 1715
Chemical Compositing of Alloying Elements, % According to EN 573-3 OTHER IMPURITIES, %
Si Fe Cu Mn Mg Zn B Each Total
0,30 0,10 0,05 0,05 0,35 0,01 0,003 0,03 0,1
0,60 0,30 0,60
Dimensions, linear mass :
The 6101 Alloy Aluminium Wire will be delivered in following diameter and unit weight range
Nominal diameter, Deviation range Linear mass
[mm] (mm) [kg/m]
9,5 ± 0,5 0,191
12,0 ± 0,5 0,305
The linear mass is calculated for the density of 2,7 kg/dm3.
The cross-section of the wire rod is similar to a circle section, with three flattened sides. Wire ovality (the difference between the large and small
dimensions of a section) will not exceed the value of the deviation range in table no.2
Mechanical and electric characteristics:
Electric characteristics
Mechanical characteristics temperature : 20ºC
Metallurgical
Alloy delivery Tensile Usual
denomination Strength Elongation Resistivity Conductivity
state μcm %IACS
Mpa A 100
Min % max max.
6101 T4 AlmgSi 150 20 3,45 51,29

Material :
Continuous Casting 6201 T4 Alloy Grade Aluminium Wire Rod.
Technical Specifications :
Guaranteed chermical composition : EN 1715
Chemical Compositing of Alloying Elements, % According to EN 573-3 OTHER IMPURITIES, %
Si Fe Cu Mn Mg Zn B Each Total
0,50 0,5 0,1 0,03 0,60 0,03 0,01 0,03 0,1
0,90 0,90
Dimensions, linear mass :
The 6201 Alloy Aluminium Wire will be delivered in following diameter and unit weight range
Nominal diameter, Deviation range Linear mass
[mm] (mm) [kg/m]
9,5 ± 0,5 0,191
12,0 ± 0,5 0,305
The linear mass is calculated for the density of 2,7 kg/dm3.
The cross-section of the wire rod is similar to a circle section, with three flattened sides. Wire ovality (the difference between the large and small
dimensions of a section) will not exceed the value of the deviation range in table no.2 Conductors
Mechanical and electric characteristics:
Electric characteristics
Mechanical characteristics temperature : 20ºC
Metallurgical
Alloy Tensile Usual
denomination delivery Strength Elongation Resistivity Conductivity
state μcm %IACS
Mpa A 100 max max.
Min %
6201 T81 Almg0,7Si 160 21 3,55 49,74
